High Power
BS2000A-4830 Series
48V 30A High Power Battery Charger (1440W)
Power1440W
Output48V / 30A@220Vac
Output Voltage39-60Vdc
Shutoff Current3A
Input100-240Vac
Max Input Current8A@220Vac
Efficiency93%
Noise≤45dB
WaterproofIP65
CommunicationCAN-bus
Aux Power12V / 3A
Battery TypesLead-acid, Gel, AGM, Sodium, Lithium
Dimensions282×166×90mm
Weight4.5 KG
Operating Temp-20~50°C
Storage Temp-40~95°C
Key Features
- CAN-bus Communication - Integrates with BMS and vehicle control systems
- 12V / 3A Auxiliary Power Output - Powers onboard electronics during charging
- Battery Activation Function - Revives deeply discharged batteries
- External 3-colour LED Indicator - Shows charging status at a glance
- Charge Interlock Protection - Prevents accidental disconnection
- Over-temperature Protection - Auto current reduction and shutdown
- Multi-protection: OTP, Reverse Polarity, Short-circuit, Over-voltage
- High efficiency (93%) reduces heat and saves energy
Applications
Application Scenarios
CAN-bus Enabled Forklifts
Designed for modern 48V forklifts with BMS communication. CAN-bus interface allows real-time data exchange with the battery management system for intelligent, adaptive charging.
AGV & Automated Systems
Ideal for 48V AGVs in automated warehouses. CAN-bus integration enables automatic charge scheduling and status reporting to fleet management software.
Heavy-Duty Industrial Use
The robust 282×166×90mm aluminium housing and IP65 protection suit demanding industrial environments with dust, oil mist, and humidity.
Dual-Voltage Sites
12V/3A auxiliary output powers door locks, lighting, or onboard computers during charging, eliminating the need for a separate auxiliary charger.
